RVL1-37 - 22-16 AWG PVC Vinyl Insulated Ring Terminals, #6 Stud, Butted Seam, 100 Pieces
VINYL (PVC) INSULATED RING TERMINALS
Ring terminals offer a tight and secure connection in high vibration areas. Simply crimp the ring terminals to your stranded wires to be attached to studs or posts. Vinyl Insulated ring terminals come in a variety of sizes and styles in a brazed or butted format.
Application Info:
Ring terminals (sometimes called split ring terminals): electrical contact is made by the flat surface of the ring, while mechanically they are attached by passing a screw or bolt through them. Their sizes can be determined by the gauge (AWG) of the conducting wire, and the interior and exterior diameters.
DIMENSIONS & FEATURES:
| Wire Range: | 22-16 AWG |
| Stud Size: | #6 |
| Terminal Material: | PVC Vinyl & Tin-Plated Copper |
| Seam: | Butted |
| T: | 0.75mm (.03") |
| L: | 20.8mm (0.82") |
| F: | 7mm (0.28") |
| E: | 10mm (0.40") |
| W: | 8mm (0.32") |
| D: | 4mm (0.16") |
| D1: | 1.7mm (.07") |
| D2: | 3.7mm (.15) |
| Temperature Rating: | 150oC - 600 Volts |
| Max Electrical Rating: | 18 AMP |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
