22 to 16 AWG Heat Shrink Quick Disconnects, Female, Tab: 0.248", Polyolefin, 25 Pieces - QDSF100-63
HEAT SHRINKABLE QUICK DISCONNECTS
Heat shrink insulated quick disconnects are suitable for a wide variety of applications from marine use to automotive and everything in between. The heat shrink is adhesive-lined and color-coded to the industry standard wire range. The terminal will seal out water, and protect the connection from corrosion. The semi-translucent heat shrink material allows for easy visual inspection of the crimped terminal. The heat shrink tube has the added advantage of acting as a strain relief on the wire for added pull strength.
DIMENSIONS & FEATURES:
| Wire Size: | 22 to 16 AWG |
| Nema Tab: | 0.248" (6.3mm) |
| Color: | Red |
| Temperature Rating: | -67oF to 221oF (-55oC to 128oC) |
| Heat Shrink Insulation: | Polyolefin |
| Terminal Material: | Tin-Plated Copper |
| D: | 4.8mm (0.19") |
| D1: | 1.6mm (0.06") |
| B: | 6.6mm (0.26") |
| E: | 21.0mm (0.83") |
| L: | 30.0mm (1.18") |
