PBDFNYD5-250 - Nylon Fully Insulated Double Crimp Piggyback Terminals - 12-10 AWG - Yellow
Piggyback disconnects can be used when other male disconnects are limited. It allows another quick disconnect to be connected to its tab. This creates more versatility in points of connection. Multiple connections allow additional circuits to be added to existing equipment without a full rework. Double crimp terminals are built with an additional inner copper barrel which: 1. Substantially reduces the strain on the wire strands. 2. Transfers strain to the wire jacket. 3. Provides a stronger connection. Double crimp terminals prevent wire terminations from becoming loose under stress or pulled out of the terminal, particularly in areas where vibrations are present.
Dimensions & Features:
Product Drawing:
None
Dimensions & Features:
| Wire Size: | 12-10 AWG |
| Color: | Yellow |
| W: | 6.6mm (0.26") |
| W1: | 6.4mm (0.25") |
| F: | 8.0mm (0.315") |
| F1: | 8.2mm (0.323") |
| L: | 24.4mm (0.96") |
| B: | 12.8mm (0.50") |
| D: | 6.6mm (0.26") |
| C: | 3.4mm (0.13") |
| Nema Tab: | 0.8 x 6.4mm (0.032 x 0.250") |
| Terminal Material: | Brass (with copper sleeve) |
| Insulation Material: | Nylon |
| Electrical Rating: | 105°C - 600 Volts |
| Amp Rating: | 24AMP |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
