Product image 1
HomeStore

LT40516 - 4/0 AWG Compression Lug - 5/16" Stud Size, 1 Piece

LT40516 - 4/0 AWG Compression Lug - 5/16" Stud Size, 1 Piece

Compression lugs are designed to terminate copper conductors. Each lug is electro-tin plated to resist corrosion. Ferrules Direct compression lugs are installed using our crimping tools as well as industry standard ones.

Dimensions & Features:

Wire Size: 4/0 AWG
Stud Size: 5/16"
Color: Purple
L: 90.6mm (3.57")
L1: 44.5mm (1.75")
L2: 25.4mm (1.00")
D: 25.4mm (1.00")
D1: 17.4mm (0.69")
D2: 14.2mm (0.56")
B: 37.2mm (1.47")
E: 8.8mm (0.35)
F: 3.1mm (0.12")
Terminal Material: Tin-Plated Copper
Temperature Rating: 90°C
Voltage Rating: 35 KV
Max Amp Rating: 230A
UL Recognized: Yes
CE Certified: Yes
RoHS Compliant: Yes

Product Drawing:

Cross References

Cross Reference Parts:

None:

Documents

Click to view product spec sheet:
