LBD2-3 - Double Crimp Vinyl Insulated Lipped Blade Terminals - 16-14 AWG

LBD2-3 - Double Crimp Vinyl Insulated Lipped Blade Terminals - 16-14 AWG

A flat blade terminal is a type of wire connection using a flat conductive blade which is inserted into a blade receptacle. Lipped flat blade terminals, specifically, have a distinctive lipped end to help lock the terminal firmly in place.

Dimensions & Features:

Wire Size: 16-14 AWG
Color: Blue
T: 0.8mm (0.03")
L: 27.7mm (1.09")
F: 17.4mm (0.69")
E: 10.4mm (0.41")
W: 3.0mm (0.12")
A: 2.1mm (0.08")
D: 5.0mm (0.20")
D1: 2.3mm (0.09")
Material: Tin Plated Copper
Insulation: Vinyl
Electrical Rating: 105°C - 600 Volts
Electrical Current: 30 AMP
UL Recognized: Yes
CE Certified: Yes
RoHS Compliant: Yes

Product Drawing:
