FD110K - Pneumatic Crimping Machine, Output Force: 1.8Tons, 1 Set

FD110K Pneumatic Crimping Press - 1.8 Ton Output Force

• "Plug 'n Play" Pneumatic Press with interchangeable crimping dies. Quick and easy to install, easier to operate
• Die sets can be changed in seconds
• Crimping Range:
  • Wire Ferrules: 0.25mm² to 50.00mm² (24 to 1AWG)
  • Insulated Terminals and other connectors: 0.14mm² to 16.00mm² (26 to 6AWG).
  • Non-Insulated Terminals and other connectors: 0.34mm² to 10.00mm² (22 to 8AWG).
• Crimping Length: 8mm - (For longer ferrules, pass through and crimp twice)
• Output Force: 1.8 Tons (17.6kN | 3,968 pound-force)
• Recommended Air Pressure: 80-100psi
• Max Air Pressure: 7 BAR
• Crimping Press Dimensions: 275x128x145mm (10.8x5.0x5.7")
• Weight: 8 Kilos (17.6 lbs)

For all applicable dies, click below:

Cross References

Cross Reference Parts:
None

Documents

Click here to view warranty information:


Click here to view instruction manual:

Videos

Check out the features of our FD110K! (Formerly the FD100K)
