16 to 14 AWG Non Insulated Blade Terminals, 1/2" Blade Length x 1/8" Width, 100 Pieces - DBNBL2-13

16 to 14 AWG Non Insulated Blade Terminals, 1/2" Blade Length x 1/8" Width, 100 Pieces - DBNBL2-13

NON INSULATED BLADE TERMINALS

Non Insulated Blade Terminals (also known as flat blade terminals) are wire connections that use a flat conductive blade which is inserted into a blade receptacle. They are designed to match interconnect requirements for components such as timers, valves, relays, mechanical switches, and wire-to-wire connections.

Formerly sold as part #: FBU-213L.

DIMENSIONS & FEATURES:

Wire Size: 16 to 14 AWG
W: 0.118" (3.0mm)
F: 0.512" (13.0mm)
L: 0.701" (17.8mm)
E: 0.189" (4.8mm)
D: 0.161" (4.1mm)
D1: 0.091" (2.3mm)
T: 0.031" (0.8mm)
Temperature Rating: 221°F (105°C)
Material: Tin-Plated Copper
CE Certified: Yes
RoHS Compliant: Yes
UL Approved: Yes
Max Electrical Current (see below):
16 AWG: 18A
14 AWG: 30A



DRAWING:


Cross References

Cross Reference Parts:
None

Documents

Click to view product spec sheet:
