BMC2AG - Silver Plated Contact - 16-12 AWG - 30 AMP
Modular power connectors are made of copper with an electro silver-plated finish for enhanced durability. They are designed for use with molded case circuit breakers, panel board equipment, and meter sockets. They provide reliable low resistance non-gendered termination of both aluminum and copper conductors.
Dimensions & Features:
Product Drawing:
None
Dimensions & Features:
| Wire Range: | 16-12 AWG |
| L | 0.63" (16.1mm) |
| E | 0.30" (7.5mm) |
| D1: | 0.11" (2.8mm) |
| D: | 0.16" (4.1mm) |
| Terminal Material: | Copper |
| Terminal Plating: | Silver |
| Current Rating: | 30A |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
Product Drawing:
Cross References
Cross Reference Parts:None
Documents
Click to view product spec sheet:Videos
