BHT1 - 22 to 16 AWG Polyethylene Heat Shrink Butt Connectors, 25 Pieces
HEAT SHRINKABLE BUTT CONNECTORS
Heat shrink butt connectors are suitable for a wide variety of applications from marine use to automotive and everything in between. The heat shrink is adhesive-lined and color-coded to the industry standard wire range. The terminal will seal out water, and protect the connection from corrosion. The semi-translucent heat shrink material allows for easy visual inspection of the crimped terminal. The heat shrink tube has the added advantage of acting as a strain relief on the wire for added pull strength.
DIMENSIONS & FEATURES:
| Wire Size: | 22 to 16 AWG |
| Color: | Red |
| L: | 36mm (1.42") |
| D2: |
1.7mm (0.06") |
| Terminal Material: | Tin Plated Copper |
| Insulation: | Polyethylene |
| Operating Temperature: |
(-40°C to 105°C) |
| Max Electrical Rating: | 600 Volts |
| UL Recognized: | Yes |
| CE Certified: | Yes |
| RoHS Compliant: | Yes |
| Max Electrical Current (22 to 16 AWG): | |
| 22 AWG: | 9 AMP |
| 20 AWG | 12 AMP |
| 18 AWG: | 17 AMP |
| 16 AWG: | 18 AMP |
DRAWING:
Cross References
Cross Reference Parts:
None
Documents
Click to view product spec sheet:
